主要技术指标(Performance Specification)
● 输出温度影响(Temperature Effect On Output)∶±0.05;±0.1%FS/10 ℃
● 输出灵敏度(Rated Output)∶1.5~2.0 mV/V
● 激励电压(Excitation)∶12 VDC
● 非线性(Nonlinearity)∶±0.05;±0.1% FS
·绝缘电阻(Insulation Resistance)∶2000 MO/100 VDC
● 滞后(Hysteresis)∶±0.05;±0.1%FS
● 输入电阻(Input Resistance)∶380±5/760±5 Q
● 重复性(Repeatability)∶±0.05;±0.1%FS
●工作温度(Operating Temperature)∶-35~+80 ℃
●输出电阻(Output Resistance)∶350±5/700±5 Q
● 零点输出(Zero Output)∶0~±1%FS
温度补偿范围(Compensated Temperature)∶室温~+60℃
●过载(Overload Capacity)∶120 %FS
●零点温度影响(Temperature ffect On Zero)∶±0.05;±0.1%FS/10 ℃
